The JMS FuelMAX V2 Dual Output Fuel Pump Voltage Booster is a performance fuel-system upgrade designed for compatible supercharged Gen 3 HEMI vehicles, including the Dodge Challenger SRT Hellcat, Charger SRT Hellcat, Challenger SRT Demon, Demon 170, Jeep Grand Cherokee Trackhawk, and Dodge Durango SRT Hellcat. Instead of immediately replacing the factory fuel pumps as horsepower and fuel demand increase, FuelMAX boosts and regulates pump voltage from 14.4 volts up to a maximum of 22 volts, helping the existing pumps deliver substantially more fuel. JMS states that FuelMAX can increase electric fuel pump output by as much as 85 percent, with support for up to 1,000 horsepower on a single pump and up to approximately 1,350 horsepower using stock dual pumps. User-adjustable voltage control, adjustable activation, and controlled voltage ramp-in and ramp-out provide flexibility when configuring the system around a specific engine and fuel combination. For pulley upgrades, E85 conversions, camshaft builds, supercharger upgrades, and other high-horsepower HEMI combinations, FuelMAX provides a practical way to increase available fuel supply while retaining compatible factory or aftermarket electric pumps.

Fuel demand increases quickly when additional power is added to a 6.2L Supercharged HEMI. Smaller supercharger pulleys, increased boost, ethanol fuels, upgraded superchargers, larger injectors, camshafts, and other airflow modifications can push the factory fuel system beyond its original operating range. When pump capacity becomes the restriction, larger injectors alone cannot provide the additional fuel volume the engine requires.

The FuelMAX V2 addresses this limitation by increasing voltage supplied to the electric fuel pumps. Rather than running maximum voltage continuously, the system can provide increased pump output when additional fuel is actually required. FuelMAX is compatible with both 12-volt and 16-volt battery systems, and JMS designed the unit to work with factory in-tank pumps as well as compatible aftermarket electric fuel pumps.

Another major benefit is adjustability. FuelMAX includes an adjustable Hobbs pressure switch that is preset at 5 psi and can be adjusted from approximately 3 to 7 psi. This allows increased pump voltage to activate as the engine enters boost. Adjustable voltage ramp-in and ramp-out can also help reduce sudden fuel-pressure spikes as pump output increases or decreases.

A green status LED provides quick confirmation of system operation, blinking when the unit is actively boosting voltage. The kit also includes the wiring harness and installation hardware necessary for integration into the vehicle’s fuel pump power circuit.

Application-specific fitment makes this FuelMAX especially relevant to modern high-performance Mopars. JMS lists compatibility with the 2018 Challenger SRT Demon, 2023 Demon 170, 2018-2023 Challenger and Charger SRT Hellcat, 2018-2021 Jeep Grand Cherokee Trackhawk, and 2021-2026 Dodge Durango SRT Hellcat.

For modified Gen 3 HEMI owners approaching the capacity of their existing pumps, the JMS FuelMAX V2 provides a proven path to greater fuel delivery without immediately converting to a completely different fuel system. Proper injector sizing, fuel pressure, pump condition, fuel type, horsepower target, and custom calibration should always be evaluated as part of the complete combination.

Looking for additional upgrades? Browse our catalog!

Specifications & Features

• Manufacturer: JMS
• Product: FuelMAX V2
• Product Type: Plug-and-Play Dual Output Fuel Pump Voltage Booster
• Part Number: P2020PPD18
• Engine Family: Gen 3 HEMI
• Primary Engine Application: 6.2L Supercharged HEMI
• Dodge Challenger SRT Demon Compatibility: 2018
• Dodge Challenger SRT Demon 170 Compatibility: 2023
• Dodge Challenger SRT Hellcat Compatibility: 2018-2023
• Dodge Charger SRT Hellcat Compatibility: 2018-2023
• Jeep Grand Cherokee Trackhawk Compatibility: 2018-2021
• Dodge Durango SRT Hellcat Compatibility: 2021-2026
• Voltage Range: Regulates and boosts fuel pump voltage from 14.4V up to 22V
• Battery Compatibility: 12V and 16V electrical systems
• Maximum Pump Output Increase: Up to approximately 85 percent
• Power Support: Up to 1,000 HP with a single pump and approximately 1,350 HP with stock dual pumps, according to JMS
• Output Configuration: Dual output
• Voltage Adjustment: User-adjustable
• Voltage Control: Adjustable ramp-in and ramp-out
• Activation: Adjustable Hobbs pressure switch
• Hobbs Switch Preset: 5 psi
• Hobbs Switch Adjustment: Approximately 3-7 psi
• Status Indicator: Green LED, blinks while voltage is being boosted
• Fuel Pump Compatibility: Compatible with factory and applicable aftermarket electric fuel pumps
• Installation: Integrates into the existing fuel pump 12V DC power feed
• Kit Contents: FuelMAX V2 booster, wiring harness, Hobbs switch, fittings, vacuum tees, vacuum hose, fuse, electrical connectors, terminals, zip ties, mounting hardware, screwdriver, and installation instructions
• Dimensions: 5 x 10 x 12 inches
• Weight: 5 lbs
• Color / Finish: Black electronic enclosure
• Manufacturing: Designed and assembled in the USA
• Primary Benefits: Increased fuel pump capacity, additional fuel delivery for higher horsepower, adjustable activation, regulated voltage, and the ability to retain compatible existing pumps
• Intended Uses: Pulley upgrades, increased boost, E85 conversions, upgraded superchargers, camshaft builds, high-horsepower street vehicles, drag racing, and modified supercharged Gen 3 HEMI applications
• Custom Tuning: Required when supporting modifications alter engine fueling requirements
• Professional Installation: Recommended
• Fitment Note: Verify exact vehicle, model year, fuel pump configuration, fuel type, injector capacity, pump condition, horsepower target, and calibration before installation.
